BRAKES
34
TANDEM MASTER CYLINDER
(TMC) :
Removal :
1. Remove the leaf screen and panel for wiper
motor mounting to have easy access to the
TMC. (For procedure refer body section)
2. Remove the air filter assembly. (For
procedure refer engine section)
3. Drain the brake fluid from the brake circuit.
(For procedure refer brake fluid draining in
this section.)
4. Remove the spring band clamp at the CMC
end and hold the CMC to reservoir connecting
line in vertically upward position to avoid any
further loss of fluid and plug the openings with
suitable cap.
5. Disconnect the electrical connection of fluid
level warning indicator from the TMC.
6. Disconnect all the outlet lines from the master
cylinder.
7. Loosen and remove the mounting nuts and
remove the TMC assembly from the vehicle.
Fitment :
For fitment follow reverse procedure of removal.
NOTE :
Make sure that lines are fitted correctly i.e.
primary outlet is connected to front brakes
and secondary outlet is connected to rear
brakes.
Connect clutch hose
After refitment bleed the brake circuit.
Do not overhaul the TMC assembly as it is
not serviceable and needs to be replaced
as an assembly.
