559 / 1595
AMT KIT
17
Screw the SCREW M6x20 for fixing OTK on
PWU body at the right torque (10 ± 1 [Nm]).
Place the WASHER M8 on top of the OTK
forth mounting arm & Screw the STUD M8-M6
for fixing OTK on MGA body at the right
torque (20 ± 1 [Nm]).
Screw the SCREW M6x20 for fixing OTK
under PWU body at the right torque (10 ± 1
[Nm]).
Fill the OTK with Tutela CS SPEED oil
(0.45Kg)
in the hydraulic circuit) as indicated on the
overall drawing and restore it after the purge
procedure
Screw the OIL TANK CAP at the right torque.
