spare gasket, with care to avoid
contamination from foreign materials (dust,
metal burrs, etc.) or surface damages.
Assemble the O-rings on the connectors.
Mount the connectors with O-rings in their
, after
lubrication with new
Lubricate with
connectors with O-rings.
Assemble the
the correct orientation,
inserting the centering pins into the fixing
h
body.
using for reference the threaded rods and
moving it parallel towards the mating surface.
body
seats come in contact with O-rings push it
slowly with appropriate load to complete the
assembly.
Unscrew the rods and screw without tighten
the three screws for fixing
