ELECTRICAL
105
ELECTRICAL
3.Pry out the glove box switch from the top utility
bin and take out it from the cutout.
INSPECTION:
Same as bonnet switch
REFITMENT:
1.Locate the glove box switch in the cutout
provided on Dashboard lower and press fit the
switch.
2.Connect the electrical connection.
3.Fit the glove box assembly.
8.10.10 REVERSE LIGHT SWITCH:
FUNCTION:
An open switch that prevents from
voltage being applied to the backup lights until the
vehicle is put in reverse. Putting the vehicle in
reverse closes the contact and applies power to
the tail lamp lights.
LOCATION:
It is located on the Gear box.
