BODY
78
9.2.43 FRONT FENDER
REMOVAL
1. Remove front bumper assembly.
(For
procedure refer bumper removal process in this
section)
2. Remove front wheel arch cover.
(For procedure
refer front wheel arch cover removal process in
this section)
3.
Remove head lamp assembly (For procedure
refer head lamp removal procedure in Electrical
section)
4. Open bonnet and remove five mounting bolts
along with washer from upper side.
5. Open the front door. Loosen and remove the
mounting screw along with the washer.
6.
Remove the sill finisher
(For procedure refer
valance cover removal procedure in this
section.)
7.
Loosen and remove one mounting screws from
bottom.
8. Loosen and remove two mounting bolts from
head lamp end and separate the fender from
vehicle.
FITMENT
For fitment follow reverse procedure of removal.
