SAFARI STORME MY14

BODY

9.2.47 SIDE FOOT STEP

REMOVAL

1. Give a suitable support to the side foot step

assembly.

2. Loosen and remove six mounting bolts as

shown below and carefully take out the

assembly.

FITMENT

For fitment follow reverse procedure of removal.

REAR FOOT STEP

REMOVAL

1. Lift the vehicle on two post lift up to comfortable

height.

2. Remove split pin and remove spring guide pivot

pin. and disengage the spring from mounting

bracket end.

3. Remove split pin and push the guide out on

both sides of foot step and take out the foot

step assembly.

FITMENT

For fitment follow reverse procedure of removal.
