ENGINE2.2LDICOR
Fig. 112
Fig. 111
l
Tighten main bearing cap mounting bolts to
specified torque (Fig. 111)
l
Check crank case main bearing parent bore
dimensions. (Fig. 112)
l
Install new pairs of main bearing shells according
to size of crank shaft main bearing journal
diameter, making sure that securing lugs of
bearing shells are properly seated in grooves
of crank case and main bearing caps.
l
Install main bearing caps with bearing shells in
their respective position on crank case. Tighten
main bearing cap mounting bolts in specified
sequence to specified torque (Fig. 113). Measure
main bearing bore
l
IFMAINBEARINGPARENTBOREDIMENSION IS
MAINTAINEDWITHINSPECIFIEDLIMITS,PROPER
MAIN BEARING BORE DIMENSION IS
AUTOMATICALLYACHIEVED.
Fig. 113
