9.2.35 GEAR LEVER BOOT
REMOVAL
1. Pull out the Lather boot from the floor console.
2. Loosen the locking nut and remove the gear
shifter knob by rotating it in anticlockwise
direction.
3. Remove the Lather boot from the gear shifter
lever.
FITMENT
For fitment follow reverse procedure of removal.
9.2.36 BONNET INSULATION
REMOVAL
1. Open the bonnet.
2. Pull out the insulation from the bonnet
assembly.
FITMENT
For fitment follow reverse procedure of removal.
NOTE
While pulling out the Bonnet insulation, care
should be taken such that clips do not get damage
if found damaged replace the same with the new
one
