ELECTRICAL
19) Remove the Ball from in side of the Annulus
assembly.
20) Use a mild steel rod and remove the jump ring
when thrust collar is in forward condition by
holding the engaging lever down wards.
16) Gently remove the Planetary Gear assembly 3
Nos. from the Annulus assembly.
17) Remove the Annulus assembly and Drive assy
from the Fixing bracket.
18) Remove engaging lever assembly.
