STEERING SYSTEM
STEERING RACK AND PINION ASSEMBLY
Removal
1. Loosen upper universal joint bolt. (Do not remove
the bolt)
2. Remove lower universal joint bolt and make
steering rack free from the steering column
assembly.
3. Remove both front wheels (Refer wheel removal
procedure/Wheels and tyres group)
4. Remove tie rod ball joint nyloc nut.
5. Remove tie rod end by using tie rod ball joint puller.
(Part No. 265458903304)
NOTE:
Steering arm should not be hammered for removal of
tie rod outer ball joints as this may lead to damage of
steering arm part.
