DRIVETRAIN
367
DRIVETRAIN
8. Rest the transaxle assembly on the Front half
and remove the rear cover by unscrewing the six
M8 Bolts (01) and remove the rear cover (02).
9. Remove the layshaft and input shaft circlip, using
a standard circlip plier.
10. Unscrew the 13 bolts on the rear half housing,
holding the front and rear half together.
11. Remove the Idler gear bolt (01) and the Magnetic
drain plug (02) and by unscrewing it. Remove the
washer (03).
12. Separate the rear half housing (01) from the front
half (02) by lifting the rear half.
