ENGINE 273 MPFI
•
Fit the front camshaft oil seal using cam shaft oil
seal drift (Part No. 2834 5890 06 07).
NOTE
Ensure that bearing caps are placed at their
respective positions according to the numbers and
direction (arrow head in front direction) engraved
on caps.
•
Check valve clearance at inlet and exhaust for both
the cylinders. If it is not within specified limit,
replace shims (Refer ‘Engine General’ Section).
•
Check camshaft thrust clearance. It should be
within specified limits.
CAMSHAFT THRUST CLEARANCE
STANDARDVALUE
WEAR LIMIT
0.1 to 0.3 mm
0.4 mm
•
Fit the water temperature sensor.
•
Place the thermostat element and thermostat
gasket.
•
Tighten hexagonal mounting bolts of thermostat
wall cap on cylinder head.
•
Fit the spark plugs using wheel spanner.
