ELECTRICALS
195
6. Remove the exhaust fan bracket bolt, nut
(Quantity 2 each) and washers (Quantity 4)
form grommet and take out the exhaust fan.
7. Remove all 4 grommet form welded bracket.
Installation:
1. Fit all 4 grommet on welded bracket (do not
reuse the grommet).
2. Fit exhaust fan bracket bolt and nut (Quantity 2
each) with washer (Quantity 4) in grommet and
tighten it as per specified torque. (5. ± 1 Nm).
