7) Unscrew the 2 nos. brush gear assembly fixing

screw from CE bracket.

8) Remove the CE bracket.

9) Remove the Brush GearAssembly use with Bullet

from theArmature assembly.

4) Separate the Solenoid switch assembly from the

starter motor.

5) Unscrew the 2 nos. through bolt from the CE

bracket.

6) Remove and separate the 2 nos. through bolt from

the CE bracket.
