ELECTRICAL
104
1.Locate and fit (
snap fit
) the switch in the cutout of
floor console gear shifter bezel assembly.
2.Connect the electrical connection of the Transfer
case switch.
3.Fit the floor console gear shifter bezel assembly
(Refer
body section
).
8.10.9 GLOVE BOX SWITCH
FUNCTION:
Glove box switch is switched on or off
in response to opening and closing of glove box.
LOCATION:
It is fitted inside the glove box on
Dashboard lower RHD in front of co-driver.
REMOVAL:
1.Remove the glove box assembly
(Refer Glove
box removal procedure in body section).
2.Disconnect the electrical connection.
