BRAKES
61
BRAKES
3 Make sure all sides of the boot have covered
the piston. Insert the piston by pushing the
hand bar against air pressure through caliper,
so that piston can be pushed into the housing
easily.
4 Ensure that seal does not get damaged due to
excessive push. If required, slightly swivel the
piston for ease of entry. The moment you get a
feel that piston has entered the seal
immediately stop air flow and then push the
piston till bottom of caliper.
5 Ensure the outer end of the dust boot is
properly seated in the piston groove and check
for free movement of the piston.
