ENGINE
143
ENGINE
•
The Catalytic converter should not be dropped
from a height. If dropped, it should not be used.
All these can keep the ‘EGR’ open when not
desired and vice versa. Either way these can seri-
ously affect power output of the engine and also the
emission levels.
! CAUTION
The Catalytic converter should not be
dropped from a height. If dropped, it should not be
used.
3.1.8.1.4.2 ON VEHICLE REPAIRS
A. POST SILENCER AND INTERMEDIATE PIPE
REMOVAL
1. Loosen and remove the mounting bolts
(1)
and
disconnect the twin pipe assembly along with the
post silencer from Intermediate pipe
(rear)
Re-
move the two rubber hanger and then take out
the twin pipe assembly along with post silencer.
2. Loose and remove the mounting bolts
(2)
from
main silencer end and remove the Intermediate
pipe assembly.
FITMENT
For fitment follow the reverse procedure
of removal
B. MAIN SILENCER
REMOVAL
1. Remove the mounting bolts from the rear end of
middle pipe assy.
2. Disconnect the Intermediate pipe connection by
removing there mounting bolts & remove rubber
hangers
(4 Nos.)
take out the Main silencer as-
sembly.
FITMENT
For fitment follow reverse procedure of re-
moval.
