BODY
86
B. TAILGATE DIMENSIONS
A, B, C and D are the Centre points of the hinges and the tailgate striker. All measurements need to be
measured with respect to these centers.
Dimensions in Rear View
SR. NO
MEASUREMENT POSITION
LENGTH (mm)
1
K - N
1333
2
L - M
1277
