BODY

56

9.2.22 INNER REAR VIEW MIRROR

REMOVAL

1. Push the mirror in the downward direction along

with the windshield to remove the same.

FITMENT

For fitment follow reverse procedure of removal.

9.2.23 FRONT ROW SEAT

REMOVAL

NOTE

The procedure for seat removal is similar for both

driver and co-driver seat.

1. Disconnect the micro switch connector.

2. Lift the floor carpet to access the front mounting

bolts and then loosen and remove mounting

bolts from front end
