BODY
34
REMOVAL
1. Pull out the steering column cover for easy
access to connectors of door wiring
harness
.(door wiring harness connector is
mounted next to cabin fuse box.)
2. Disconnect the wiring harness and door
electrical connections through the access below
steering wheel as shown In figure
3. Remove the door trim.
(For procedure refer
door trim removal in this section.)
4. Open the door and remove the check strap.
5. Support the door from the below and remove
the door hinges
6. Slowly pull out the door and remove the wiring
harness carefully which was disconnected
earlier.
FITMENT
For fitment follow the reverse procedure of
removal.
