AIR CONDITIONING
56
Connector detail:
Pinout details
PIN NO
DESCRIPTION
1
Solar sensor Input to control panel
2
Analog gnd
Removal & Refitment of OAT sensor
Removal:
1. Open the bonnet.
2. Disconnect the electrical connection.
3. Carefully pull out to backward the ambient temp sensor from its mounting plastic Clip.
4. Take out the OAT sensor.
Refitment:
1. For fitment procedure, follow the reverse procedure of “Removal”.
