ZEST AND BOLT - page 949

AIR CONDITIONING
54
Removal &
Refitment procedure of Solar load sensor
: Removal:
1.
Pry out the front defrost grill.
2.
Disconnect the electrical connection of solar load sensor.
3.
Insert wedge as shown in fig and lift up the adapter.
4.
Repeat step 1 for diametrically opposite end of adapter.
5.
Take out the sensor.
Refitment:
1. Push and rotate the solar sensor adapter
