AIR CONDITIONING
47
Removal and Refitment of control panel
Removal:
1. Remove the center utility bin.
2. Remove four mounting screws of control
panel.
3. Disconnect the electrical connection of panel.
4. Take out the control panel.
Refitment:
1. For
fitment
procedure, follow the reverse
procedure of “Removal”.
