AIR CONDITIONING
60
11.18.10 Diagnosis Trouble Codes
B1F2B-12
Air Conditioning Compressor Request – circuit short to battery
B1F2B-11
Air Conditioning Compressor Request – circuit short to Ground
B1F3E-71
Temperature Door Control Motor - Actuator stuck
B1F3E-54
Temperature Door Control Motor Calibration Fault
B1F2D-12
Temperature Door Control Motor Drive Line - Circuit Short to Battery
B1F2D-11
Air Temperature Motor Drive Line- Circuit Short to Ground
B1F2D-13
Air Temperature Motor Drive Line- Circuit Open
B1F47-13
Air Temperature Feedback Power Supply- Circuit Open
B1F20-11
Air Temperature Feedback Power Supply- Circuit Short to Ground
B1F20-12
Air Temperature Feedback Power Supply- Circuit Short to Battery
B1F1F-15
Air Temperature Feedback Signal - Circuit Short to Battery or Open
B1F1F-11
Air Temperature Feedback Signal - Circuit Short To Ground
B1F2F-13
Blower Motor Drive Signal - Circuit Open
B1F28-12
Blower Motor Diagnostic Feedback OR Blower Motor DTC - Circuit Short to Battery
B1F28-14
Blower Motor Diagnostic Feedback - Circuit Short to Ground or Open
B1F2F-12
Blower Motor Drive Signal - Circuit Short to battery
B1F2F-11
Blower Motor Drive Signal - Circuit Short to Ground
B1F2A-12
Cabin Temperature Sensor - Circuit Short to Battery
B1F2A-14
Cabin Temperature Sensor - Circuit Short to Ground or Open
B1F23-15
Evaporator Temperature Sensor Signal - Circuit Short to Battery or Open
B1F23-11
Evaporator Temperature Sensor Signal - Circuit Short to Ground
B1F46-13
Fresh Air/RECIRC Feedback Power Supply - Circuit Open
B1F2C-13
Fresh Air/RECIRC Motor Drive Line- Circuit Open
B1F2C-12
Fresh Air/RECIRC Motor Drive Line- Circuit Short to Battery
B1F4B-56
BCM configuration Error- Invalid/Incompatible Configuration
B1F2C-11
Fresh Air/RECIRC Motor Drive Line- Circuit Short to Ground
B1F1E-12
Fresh Air/RECIRC Feedback Power Supply - Circuit to Battery
B1F1E-11
Fresh Air/RECIRC Feedback Power Supply - Circuit Short to Ground
B1F1D-15
Fresh Air/RECIRC Feedback Signal - Circuit Short to Battery or open
B1F1D-11
Fresh Air/RECIRC Feedback Signal - Circuit Short to Ground
B1F3F-71
Fresh Air/RECIRC Drive Motor – Actuator stuck
B1F3F-54
Fresh Air/RECIRC Drive Motor – Missing calibration
U161B-64
HuCCmConfigAck Data Mismatch or Not Received From HU - Signal Plausibility Failure
B1F2E-12
Air Distribution Motor Drive Line– Circuit short to Battery
B1F2E-11
Air Distribution Motor Drive Line– Circuit short to Ground
B1F3D-54
Air Distribution Motor Drive Line– Missing calibration
B1F3D-71
Air Distribution Motor Drive Line– Actuator stuck
B1F22-12
Air Distribution Feedback Power Supply – Circuit short to Battery
B1F22-11
Air Distribution Feedback Power Supply – Circuit short to Ground
