AIR CONDITIONING
46
8. AUTO ON SELECTION BUTTON:
To put the automatic climate control in fully-
automatic mode:
A. Press the ‘AUTO’ button.
B. Set the desired temperature by turning
temperature control knob. The display will
show all the functions during ‘AUTO’ mode.
C. The system automatically selects the proper
mix of conditioned and/or heated air that will,
as quickly as possible, raise or lowers the
interior temperature to your preference.
D. When you set the temperature to its lower
limit (Lo) or its upper limit (Hi), the system
runs at full cooling or heating only. It doesn’t
regulate the interior temperature.
Semi-automatic Operation:
You can manually select various functions of the
climate control system when it is in fully
automatic mode. All other features remain
automatically controlled .Making any manual
selection causes the word ‘AUTO’ in the display
to go OFF and overridden setting is displayed.
System will remain in semiautomatic mode till
‘AUTO’ is re-pressed.
9. TEMPERATURE CONTROL KNOB:
Turning the temperature control knob clockwise
increases the temperature of the air. The desired
temperature will be increased by steps of 0.5ºC.
User can select temperature range from 18ºC to
30ºC. Whereas the anti-clockwise direction
decreases the temperature.
When you set the temperature to its lower limit
(Lo) or its upper limit (Hi), the system runs at full
cooling or heating only. It doesn’t regulate the
interior temperature.
10. “OFF” BUTTON:
Press the OFF button to switch OFF The system.
OFF will be displayed on the display.
11. Incab Sensor
