ZEST AND BOLT - page 913

AIR CONDITIONING

11.6.2 REMOVAL OF WIRING HARNESS

CONNECTORS FROM CONTROL PANEL

1. For removing the connector press the snap

and pull the connector outside.

2. For removing the connector 2 press the snap

and push the lever.

11.6.3 SERVICING OF BLOWER ASSEMBLY

1. Remove wiring harness connector.

2. Remove motor cooling pipe.

3. Unscrew the blower assembly mounting

screws. 3 Nos.

4. Remove the assembly.
