ENGINE 1.3 QUADRAJET (75PS)
59
22.Replace the engine oil filter mounting complete
with the engine oil filter and engine oil filler fitting
and secure by tightening the M6 bolt s to the
specified torque of 0.8 ~ 1.0 Kg-m.
NOTE :
Q
Ensure the gasket is present, undamaged and
correctly positioned.
23.Place the water pump rigid inlet pipe, complete
with O-ring in position and secure it using the bolts.
NOTE :
Q
Fit the rigid pipe in the crankcase very carefully to
ensure the O-ring is correctly positioned.
24.Place the rpm sensor in its housing and secure it
by tightening the M6 bolt to the recommended
torque of 0.8 ~ 1.0 Kg-m .
25 Fit the engine oil heat exchanger protection.
