ELECTRICAL
103
FOR 20 PIN CONNECTOR
SR.
NO
DESCRIPTION
TYPE
OF
INPUT
INPUT
/OUTPUT
ACTIVE
LEVEL/
STATE
DIAGO-
NASTIC
IC-Low
end
IC-High
End
1
NC
2
NC
3
NC
4
NC
5
NC
6
Front Fog HW IN
Digital
Input
High
NA
PP
PP
7
Rear Fog HW IN
Digital
Input
High
NA
PP
PP
8
Driver Door Open IN Digital
Input
Low
NA
Y
NA
9
Turn Right IN
Digital
Input
High
NA
Y
NA
10 Key IN
Digital
Input
High
NA
Y
NA
11 NC
12 NC
13 NC
14 NC
15 NC
16 NC
17 Park Bulb IN
Digital
Input
High
NA
Y
NA
18 All Other Door Open
IN
Digital
Input
Low
NA
Y
NA
19 NC
20 Turn Left IN
Digital
Input
High
NA
Y
NA
NA-Not applicable, PP- Package protected, Y- applicable.
12.24.5 FUEL GAUGE DETAILS:
Fuel level indication:
FUEL VS RESISTANCE TABLE
FOR INSTRUMENT CLUSTER HIGH END
SEGMENT
TANK
LEVEL(Lit)
RESISTANCE
(OHMS)
BAR ON
RESISTANC
E(OHMS)
BAR OFF
RESISTANC
E (OHMS)
LOW FUEL
WARING TT
TOLERANCE(±2 OHMS)
SHORT CIRCUIT
5
BLINK @
2Hz
6
42
8
10
22
LFW OFF
5
35.7
24
26
38
LFW OFF
4
29.3
40
42
54
LFW OFF
3
23
56
58
74
LFW OFF
2
15.5
76
78
95
LFW OFF
1
8
97
99
109
LFW ON
with 2nd bar
OFF
1 BAR BLINK
4
111
IGN
ON
LFW ON
OPEN CIRCUIT
135
BLINK @
2Hz
