ELECTRICAL
100
REMINDER FEATURES
Key In reminder
While leaving your vehicle, if you forget key inside the vehicle in Ignition OFF position, buzzer will provide
sound warning. Remove Key to stop the warning.
Park Bulb ON reminder
While leaving your vehicle, if you forget to turn OFF the Head Bulbs, buzzer will provide sound warning.
Switch off Park Bulbs to stop the warning. Do not forget to turn OFF your Head Bulbs as it may drain your
Car Battery.
Park Brake ON reminder
If Park Brake is applied and vehicle is driven, telltale will turn ON and buzzer will provide sound warning
above 5km/hr continuously. Disengage the park brake to stop sound warning.
Reverse Gear reminder
If Reverse Gear is engaged by you, sound warning for 1 second will be given to alert you. This chime is
applicable for both Manual and AMT transmission vehicles.
Seat Belt reminder
If seat belt is not buckled and vehicle speed goes above 25 kmph, audio alarm 1 will start. Audio alarm 1 will
continue for 90 seconds. Audio alarm 1 will stop when vehicle speed goes below 4 kmph.
If seat belt reminder is unbuckled and 90 seconds of audio alarm 1 is completed, Audio alarm 2 will start.
Audio alarm 2 will continue for 90 seconds. Audio alarm 2 will stop when vehicle speed goes below 20 kmph.
Seat belt telltale will remain continuously ON when audio alarm is active.
BUZZER SPECIFICATION
QMB - 12 S/L
Spl
MIN. 86 dB
TYP. 97 dB
Rated Voltage
12 Vp-p
Rated Frequency
2048 Hz
Mean Current Consumption
MAX 40 mA
Operation Temperature
-40
C TO +100
C
External Size
16mm x 14mm
Mass
7g
