ELECTRICAL
14
DEF Low Level 7
DEF Quality Level is reduced as per following
When DEF Quality low, Text alert & Telltale
will
triggered as per below images shown. Subsequent
triggers will come from level 1 to level 5 when driver
continues to drive Vehicle without correcting DEF
Quality. From Level 5 continuous chime & text
Message activated. At Level 7 Text alert will be
come on screen and vehicle will not start until DEF
Quality corrected.
DEF Quality Low Level 1
DEF Quality Low Level 2, 3, 4, 5
DEF Quality Low Level 6
DEF Quality Low Level 7
SCR Fault Level is reduced as per following
When SCR Fault present in SCR System, Text alert
& Telltale
will triggered as per below images.
Subsequent triggers will come from level 1 to level 5
when driver continues to drive Vehicle without
correcting SCR Fault. From Level 5 continuous
chime & Text Alert activated. At Level 7 Text alert
will be will be come on screen and vehicle will not
start until SCR Fault not corrected.
SCR Fault Level 1
SCR Fault Level 2, 3, 4, 5
