TELL TALES COLOR
INDICATOR
REMARKS
Speed Limit
bulb
Amber
When Vehicle Speed cross 80 Km/hr then Speed Limit
Warning Indicator will turn ON along with one time Chime per
2 Minute (Audible Warning).
If Vehicle Speed crosses 120 Km/hr then along with Speed
Limit Warning Indicator, Chime will start continuously ON till
vehicle speed is above 120 Km/hr.
Once Vehicle Speed is reduce below 120 Km/hr but above 80
Km/hr, then Continuous Chime will stop but Speed Limit
Warning Indicator will remains ON continuously with one time
Chime per 2 Minute (Audible Warning).
When Vehicle Speed is reduce below 80 Km/hr, then Speed
Limit Warning Indicator along with Chime ( if it On ) will gets
turns OFF.
Diesel
Particulate
Filter bulb
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and should
go ‘OFF’ after the engine starts. This symbol comes ON when
Diesel Particulate filter in exhaust system is malfunctioning. At
this stage, take the car to the nearest Authorized Service
outlet.
CNG Bulb
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and should
go ‘OFF’ after 4 seconds. This symbol comes ON when CNG
fuel mode is activated.
Fuel Filter
Clogging
Telltale
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and should go
‘OFF’ after 4 seconds. This symbol comes ON when Fuel Filter
Clogging warning is activated (if applicable)
CITY
Blue
This symbol lights up when the ‘IGN’ is turned ‘ON’ and should go
‘OFF’ after 4 seconds.
CITY lamp ON indicates City drive mode. This mode is used to
achieve optimum torque with fuel economy.
ECO
Green
This symbol lights up when the ‘IGN’ is turned ‘ON’ and should go
‘OFF’ after 4 seconds. This symbol comes ON when ECO driving
mode is activated (if applicable).
SPORT
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and goes ‘OFF’
after 4 seconds.
This symbol comes ON when SPORT driving mode is activated
when more torque is required.
DRL indication
Amber
This symbol illuminates when the Day Time Running lamp is ‘ON’.
DRL are used for increasing the visibility of the vehicle to other
driver during day time. To activate and deactivate DRL, keep the
Ignition switch is ‘ON’ position and switch ON-OFF parking lamp
twice within approx. 3 seconds.
AMT/AT Fault
Indication
Amber
When ignition is turned ‘ON’, this symbol comes ‘ON’ for four
seconds and goes ‘OFF’.
This symbol shall continue to remain 'ON' or shall come 'ON'
after Ignition On pre-check if there is a problem in the AMT
system.
Press Brake /
Clutch (Used in
PEPS Vehicles)
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and remains
ON until user press clutch / brake to start the engine. This
symbol is turns OFF when vehicle is in Cranking / Running
Mode.
