225 / 745
C635 TRANSAXLE
38
9. Remove Console Lower trim Assembly.
10.Remove two screws & six trim clips & take out
Console Rear Storage Assembly with Auxiliary
USB.
11.Remove 4 screws on IP & 2 screws on GS
Bracket of Main console structure Assembly
with PEPS antenna & wiring harness.
12.Open the clips and release the gear selection
cable.
13.Disengage the gear engagement cable end
from the gear shifter housing.
