C635 TRANSAXLE
44
5. Unsnap Mid Trim Gear Shifter Bezel Assembly
& pass it through bellow assembly.
6. Remove Console Lower trim Assembly.
7. Remove two screws & six trim clips & take out
Console Rear Storage Assembly with Auxiliary
USB.
8. Remove 4 screws on IP & 2 screws on GS
Bracket of Main console structure Assembly
with PEPS antenna & console wiring harness.
9. Disengage the gear engagement cable end
from the lever by rotating the cable to one side
and prying it off in the direction that continues
the rotating motion.
10.Open the clips and release the gear selection
cable.
