KRYOTEC ENGINE
145
to engine block stud and tighten to the proper
torque specification (Torque Specifications).
7. Install the starter (1a) with a new gasket and
tighten the bolts (1b) to the proper torque
specification (Torque Specifications).
8. Connect the ground cable to the starter and
tighten the nut to the proper torque specification
(Torque Specifications).
9. Connect the battery positive cable to the starter
and tighten the nut to the proper torque
specification (Torque Specifications).
10. Install the DPF mounting bracket and tighten
the bolts to the proper torque specification (Torque
Specifications).
11. Install the DPF to the mounting bracket with a
new gasket and tighten the nuts to the proper
torque specification (Torque Specifications).
12. Install the DPF to turbocharger clamp (1) and
tighten the nut to the proper torque specification
(Torque Specifications).
13. Install the turbocharger heat shield and tighten
the bolts to the proper torque specification (Torque
Specifications).
14. Connect the exhaust gas hose and tighten the
clamp to the proper torque specification (Torque
Specifications).
15. Install the pressure sensor tube and tighten the
fittings to the proper torque specification (Torque
Specifications).
16. Connect the DPF temperature sensor wire
harness connector.
17. Connect the upstream oxygen sensor wire
harness connector.
18. Connect the exhaust gas temperature sensor
wire harness connector.
19. Install a new O-ring seal to the PTU.
20. Install the PTU (1a) to the transmission with the
bolts (1b) tightened to the proper torque
specification (Torque Specifications).
21. Connect the power transfer unit actuator wire
harness connector (1).
