NEXON EV
X114H
DTC Troubleshooting Data
Version: 1.0
Date: 11-12-2019
`
28
Author: Prashant Ghadigaonkar/ Samir Tikhe
Copyright © TATA MOTORS Ltd.
This document must not be used in anyway, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:-
Flow Diagram or table format for diagnosing the fault code
Step no. Description
Check Point
if YES
if NO
1
Remove the 12V LV
battery negative
terminal.
After a minute connect
the 12V LV battery
negative terminal &
"Ignition Switch" to ON
position.
Crank and wait for 2
minutes.
Check for the fault code.
Fault code P130500
is Present?
Go to step 2
Repair
Complete
2
Turn Ignition switch OFF
and remove the LV
battery negative terminal,
Check the continuity
between the KL30 and E-
drive Battery Fuse Out.
Is there a proper
continuity?
Go to step 3
Make the
connection
proper and
check the
fault code
again.
3
Check for the E-
DRIVE_BATT(5A) fuse
EF25 LV fuse
IS E-
DRIVE_BATT(5A)
LV Fuse blown?
Replace the fuse
and go to step 1
Go to step
4.
4
Check for DC-DC
converter output under
voltage fault
Check DC-DC
converter DTC
P130018 and
P130019
Refer Trouble
shooting code
P130018 and
P130019.Check
this fault code
again.
Go to step 5
5
Check for fault code
again
Fault code P130500
is present again?
Contact the
authorized dealer
and replace the
OBC.
Repair
Completed.
DTC
’
s confirmation:-
After rectification, ensure the following points by referring E-drive parameters using TML
diagnostic tool before handing over to customer.
a)
Check the torque value.
b)
Check whether the vehicle runs properly in Forward and reverse direction.
Schematic Block Diagram:-
Refer the LV schematic for more details
