NEXON EV
X114H
DTC Troubleshooting Data
Version: 1.0
Date: 11-12-2019
`
3
Author: Prashant Ghadigaonkar/ Samir Tikhe
Copyright © TATA MOTORS Ltd.
This document must not be used in anyway, such as copying and redistributing to third parties, without the consent of author.
Terminologies
Sr no. Term/Abbreviation
Description
1
LV
Low Voltage
2
HV
High Voltage
3
E-drive
Electric drive with Motor, motor
controller and gear box
4
MCU
Motor Controller Unit
5
OBC
On-board Charger
6
DCDC
DC-DC converter
7
VCU
Vehicle Control Unit
8
CP
Control Pilot
9
BMS
Battery Management System
10
CAN
Controlled Area Network
9
SCI
Serial Communications Interface
10
A/D
Analog to Digital
