1.2L REVOTRON ENGINE
45
Intercooler and Hoses
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1
Intercooler Assy.
2
Hex. Flange Screw M6x14 (2 Qty.)
1.0
3
Spring Band Clamp 49Dx12W (2 Qty.)
4
Hose TC Pipe To Intercooler
5
Spring Band Clamp 53Dx12W (2 Qty.)
6
Hex. Flange Screw M6x25 (2 Qty.)
1.0
7
Assy. Isolator (For IC intake Pipe) (2 Qty.)
8
Pipe Assy. TC To IC
9
Spring Band Clamp 53Dx12W
10
Hose, TC Pipe To Intercooler Pipe
11
Spring Band Clamp 55Dx12W
12
Hex. Flange Screw M6x12
1.0
13
Spring Band Clamp 53Dx12W
14
Hose, IC Pipe To Intake Manifold
15
Spring Band Clamp 60Dx12W
16
Sensor, Air Temperature
17
Hex. Flange Screw M6x18
1.0
18
Hose, IC Pipe To Intake Manifold
19
Spring Band Clamp 53Dx12W (2 Qty.)
20
Pipe Assembly, IC To IM
21
Hose (IC To Intake Manifold)
22
Hex. Flange nut AM6 (2 Qty.)
1.0
23
Elbow, TC Compressor Outlet
24
Gasket, TC Outlet To IC Pipe Assy.
