1.2L REVOTRON ENGINE
42
Engine Suspension
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Nyloc Nut M10
6.1 ~ 6.6
2 Harden Washer 10.5
3 A-Mount Arm
4 A-Mount
5 Hex Flange Bolt (2 Qty)
6.1 ~ 6.6
6 Bracket, A-Mount
7 Hex Flange Bolt (Front Pulley) (2 Qty)
6.1 ~ 6.6
8 Hex Flange Bolt (Conical)
10.7 ~ 11.2
9 Hex Flange Screw M10x30 (3 Qty)
6.1 ~ 6.6
10 Hex Flange Bolt (Conical)
10.7 ~ 11.2
11 C-Mount
12 Hex Flange Screw M10x30
6.1 ~ 6.6
13 Hex Flange Screw M10x30 (4 Qty)
4.0 ~ 4.5
14 B-Mount Bracket
15 Socket Head Cap Screw (2 Qty)
6.1 ~ 6.6
16 Reinforcement Plate
17 Hex Flange Screw M8x12 (2 Qty)
2.0 ~ 2.5
18 Reinforcement Plate
19 B Mount Assy
20 Harden Washer 10.5 (2 Qty)
21 Screw M10x1.25x30 (2 Qty)
6.1 ~ 6.6
22 Hex Flange Nut Am12x1.25 (2 Qty)
10.7 ~ 11.2
23 Washer, Plain (2 Qty)
24 Stud B Mount (2 Qty)
25 Hex Flange Bolt M12x65
10.7 ~ 11.2
