244 / 1006
1.5L REVOTORQ ENGINE
40
EGR Valve, Thermostat and Components
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Intercooler Assy
02
Hose Clamp
03
Hose,IC Outlet To Charge Air Pipe
04
Clamp Assy
05
Hose,EVRV To EGR Cooler
06
Coolant Temperature Sensor
07
Water Box
08
Gasket (For Water Box)
09
Hex Fl Nut BM6 (Qty. 4)
1 + 0.2
10
Thermostat Assy
11
Cover, Thermostat
12
Bracket Assy,EVRV Mtg
13
H/Fl Bolt M6x45 (Qty. 3)
1 + 0.2
14
One Way Check Valve W/ Hose
15
Assy. Vacuum Modulator (BS-IV)
16
Hex Fl Nut BM6 (Qty. 2)
1 + 0.2
17
Hose,EVRV To Air Intake
18
Hose Clamp
19
Hose Turbocharger To Pipe
20
Support Bracket ( TC To Intercooler Hose )
21
Pipe Assy,Turbocharger Hose To IC Hose
22
Bracket Assy (TC To IC Pipe)
23
Hex Fl Nut AM6 (Qty. 2)
0.95
24
Hex Fl Nut AM6 (Qty. 2)
0.95
25
Bracket,TC To IC Pipe Mtg
