241 / 1006
1.5L REVOTORQ ENGINE
37
Engine Suspension
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
A Mount
02
Washer (Qty. 2)
03
Hex Fl Bolt (Qty. 2)
6.1 -6.6
04
Hex Fl Bolt M10x65 (Qty. 2)
4.5
05
Rubber Stopper Assy RH
06
Stopper Bracket RH Side
07
Hex Thin Nut M12
08
Hex Fl Screw M8x20 (Qty. 2)
2.5
09
Hex Flange Bolt Conical
10.7 – 11.2
10
C Mount
11
Hex Flange Bolt Conical
10.7 – 11.2
12
Stopper Bracket LH Sid
13
Rubber Stopper Assy LH
14
Hex Fl Scr M10x35
6.1 – 6.6
15
Hex Fl Nut Am12x1.25
16
H/Fl Scr M10x30
6.1 – 6.6
17
Reinforcement Plate
18
Socket Head Cap Screw (Qty. 2)
2 – 2.5
19
Washer (Qty. 2)
20
Scr M10x1.25x30 (Qty. 2)
6.1 – 6.6
21
H/Fl Bolt M12x65
5.5 Pre Torque
and 10.7 – 11.2
22
Hex Fl Nut Am12x1.25 (Qty. 2)
5.5 Pre Torque
and 10.7 – 11.2
23
Washer (Qty. 2)
