1.5L REVOTORQ ENGINE
43
Crankcase and Components
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Cylinder Crankcase (Non Linered)
02
Stiffening Bracket Assy., Front
03
Hex. Flange Screw M10x18 (Qty. 2)
4.0
04
Hex. Bolt (M. B. Cap) (Qty. 10)
5.0 +
90
ᵒ
turn
05
Main Bearing Cap (Qty. 5)
06
Dipstick Tube Assy.
07
Hex Fl Scr M6x12
08
Bracket,Dipstick Tube Mtg
09
Dipstick Assy.
10
Gasket, Cylinder Head
11
Stiffening Bracket Assy.
12
Hex. Flange Screw M10x22 (Qty. 2)
4.0
13
Hex. Flange Screw M10x30 (Qty. 2)
4.0
14
Stiffener Bracket, Powertrain,
15
Screw M6x20 (Qty. 6)
1.0+0.2
16
Crankshaft Oil Seal (Rear)
17
Cover, Crankcase, Rear
Both Side
18
Rubber Asbestos Gasket 0.5 Thk
