1.5L REVOTORQ ENGINE
20
Air Filter, Snorkel, Blow By Pipe
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Resonator Assy.
02
Bracket, Snorkel
03
Washer (Qty. 2)
04
Hex. Flange Bolt M8x25 (Qty. 2)
2.3
05
Air Filter Assy.
06
Hex. Flange Screw M6x30 (Qty. 2)
0.95
07
Washer A6.4 (Qty. 2)
08
Bush (Qty. 2)
09
Long Spacer
1.0
10
Foam, Air Filter
11
Spring Band Clamp 27dx12w
12
Hose (Oil Sep To Air Intake Hose)
13
Spring Band Clamp 21dx12w
14
Clamp, Worm Drive (40-60/9)
3 – 3.5
15
Pipe Assy.,HFM Sensor To TC
16
Clamp, Worm Drive (60-80/9)
3 – 3.5
17
Air Mass Flow Sensor
18
Clamp, Worm Drive (Qty. 2) (60-80/9)
3 – 3.5
19
Hex. Flange Screw M8x18
2.3
20
Hex. Flange Bolt M8x28
2.3
21
Bracket Assy.,Air Filter Mtg (Rear)
22
Rubber Grommet (On Eng. For Air Filter)
23
Air Filter Element Assy.
24
Elliptical Hose Clamp
25
Rubber Hose
