222 / 1006
1.5L REVOTORQ ENGINE
18
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
23
Adaptor (For Oil Cooler & Oil Filter)
3.0
24
Oil Cooler Assy
Apply Oil
25
Spring Band Clamp 23dx12w (Qty.2)
26
Hose, EGR Cooler Outlet
27
Spring Band Clamp 25dx15w
28
Spring Band Clamp 23dx12w
29
H/Fl Screw M8x12
30
Spring Band Clamp
31
Gasket
32
Hex Fl Screw M6x18 (Qty.2)
1+0.2
33
Tc Oil Return Line
34
Gasket
35
Pipe Union Bolt (For Oil Feeder & Boost
Sensor Line) (Qty.2)
2.0
36
Oil Feeder Pipe Assy, Cyl Head To Tc
37
SEALING WASHER 10x14 (Qty.4)
38
Hex Fl Screw M6x18 (Qty.2)
1+0.2
39
Oil Sump Gasket
40
Oil Sump Gasket
