219 / 1006
1.5L REVOTORQ ENGINE
15
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
26
H/Fl Bolt M8x45 (4 Qty.)
2.9 + 0.3
27
Fuel Pr Pipe Assy, Rail To Inj (4 Qty.)*
2.5 With
Sleeve
3.0 Without
Sleeve
28
Fuel Rail Assy
29
Fuel Pr Pipe Assy, Pump To Rail
30
HP Pump Assy
31
Timing Gear (Fip)
32
Nut (Fip) (For Fip Gear)
5.0
33
Hex Fl Screw M6x16
1.0
34
Hex. Bolt (M8x75.5) (3 Qty.)
2.7 + 0.3
35
Hex Fl Scr M6x12 (1 Qty.)
36
Hex Fl Bolt M8x38 (2 Qty.)
2 + 0.3
Note:-
•
This Symbol indicates critical tightening torque.
*
Cap connector for fuel pressure line M14x1.5 (H.P. line with sleeve)
*
Cap connector for fuel pressure line M14x1.5 (H.P. line without sleeve)
