BODY
68
USE GREASE POLYLUB GLY 151 (PART NO.
006.091001) ONLY
NOTE:
Pl. check the grease qty and If observed dry,
then apply the grease as per the process
mentioned.
5. Do not apply to the outer surface of the rail
where mechanism does not operate.
6. Apply inside the grooves, not the outer
surface.
7. Do not apply too much grease, a thin layer is
enough.
NOTE:
Below are very important for quality of cleaning
and maintaining, to be followed strictly:
When cleaning, the cloth must be inserted into the
rail grooves, not only surface.
When apply grease, make sure to use small brush,
as big brush cannot reach inside the grooves.
