ELECTRICAL
8
TELL TALES COLOR
INDICATOR
REMARKS
Key Not
Detected (Used
in PEPS
Vehicles)
Red
This symbol lights up when the valid smart key is not detected
inside the vehicle.
Cruise Control
lamp
Green
This symbol lights up when the ‘IGN’ is turned ‘ON’ and shall go
‘OFF’ after 4 sec.
The Cruise Control is used to indicate the status of cruise
control system to the driver. Lamp ON indicates cruise control
feature is present and it is activated
ESP
Amber
If continuously ON then ESP system is at fault condition, Please
take your vehicle to nearest TATA authorized service center at
the earliest.
TPMS (Tire
Pressure
Monitoring
System)
Amber
TPMS warning indicator comes ‘ON’ for 4 seconds, when
ignition is turned ‘ON’. Then it will turn OFF, If it remains ON
then one of the following fault is present in vehicle tires.
Low Tire Pressure (warning)
High Tire Pressure (warning)
High Tire Temperature (warning)
Air Leakage (warning)
TPMS Sensor Missing or Sensor Malfunction (Error)
TPMS warning indicator will blink for 4 sec along with audio for
warnings and 20 sec for error.
Low DEF Level
Warning
Indicator
Amber
When DEF level becomes low this indicator will glow. This
indicator monitors for emission issues.
SCR Fault
Indicator
Amber
This feature monitors the catalyst health & warns if there is a
malfunction.
DPF warning
Indicator
Amber
DPF warning indicator comes ‘ON’ for 4 seconds, when ignition
is turned ‘ON’. Then it will turn OFF.
This feature monitors the clogging of exhaust gas filter. If the
clogging in more than some level, this warning comes out.
HHC Fault
indicator
Amber
In case of malfunction in HHC system this indicator will glow. It
will remain ON until fault recov ers.
HDC Fault
indicator
Amber
In case of malfunction in HDC system this indicator will glow. It
will remain ON until fault recovers.
