1.2. TELL TALES INFORMATION
TELL TALES COLOR
INDICATOR
REMARKS
Diesel Pre-
Heat / Glow
plug indicator
Amber
Illuminates momentarily when ignition is switched ‘ON’ to
indicate that the glow plugs are active. It will continuously
illuminate when engine is getting preheated. Start the engine
only after the indicator goes off.
Turn Signal
Green
Indicates direction indicated by the turn signal. Blinks along
with buzzer while operating left/right turn indicator only when
ignition is switched ‘ON’.
Both telltales shall blink simultaneously when Hazard switch is
pressed.
Tick-Tock sound shall be given when any one or both the
telltales are ON.
High Beam
Blue
Illuminates when the high beam head bulbs are switched ON
or flashed.
Low Oil
Pressure
Red
When the Ignition is turned ‘ON’, this symbol lights up and
goes ‘OFF’ as soon as the required engine oil pressure is
developed after starting the engine.
Warning:
If the low oil pressure indicator does not glow or remains ‘ON’
with the ‘IGN’ ‘ON’ and engine is running, it indicates a fault in
the electrical circuit / lubrication system. Take your car to a
TATA Authorized Service Centre.
Battery
charging/
engine
warning
Red
Illuminates momentarily when ignition is switched ‘ON’ once is
cranked, it goes OFF.
NOTE:
If it remains ‘ON’ while the engine is running, it indicates that
the battery is not getting charged. Switch off all unnecessary
electrical equipment and get the problem attended at TATA
authorized Service center.
Park Brake
cum Low
Brake
Fluid/ABS or
EBD
Malfunction.
Red
This indicator comes ‘ON’ for approximately 4 seconds when
ignition is turned 'ON' and goes ‘OFF’. If it remains ‘ON’, it may
indicate:
1. Brake fluid level is low.
2. Parking brake is applied. It shall go ‘OFF’ when it is
released.
3. Fault in EBD (Electronic Brake force distribution) system.
