DRIVESHAFT (AT)
11
4.Remove and discard the retaining clip.
5.Remove and discard the Constant Velocity (CV)
joint boot.
FITMENT
1. Clean and inspect the components for
deterioration.
Important: Extreme cleanliness must be exercised
when handling these components.
2. Install a new retaining clip.
3. Install a new Constant Velocity (CV) joint boot
& small clamp.
4. Pack the outer CV joint with the grease
supplied.
5. Install the old halfshaft nut onto the CV joint
as illustrated to protect the thread.
6. Using a suitable soft faced hammer, strike the
CV joint in the direction shown.
