KRYOTEC ENGINE
141
3. Install the flywheel (1) and hand tighten the bolts
(3).
4. Install the 1860846000 flywheel holder tool (2).
5. Tighten the flywheel bolts (3) to the proper
(Torque Specifications).
6. Remove the 1860846000 flywheel holder (2).
C. ENGINE (MANUAL TRANSMISSION)
SEPARATION AND REASSEMBLY
REMOVAL
1. Connect a hydraulic crane and 1871001700
Sling to the lifting brackets on the powertrain.
2. Remove the bolts (1a) and (1b) and remove the
PTU support bracket (1c).
3. Disconnect the power transfer unit actuator wire
harness connector (2).
4. Remove the bolts (1a) and remove the PTU (1b)
from the transmission.
