KRYOTEC ENGINE
140
8. Install the clutch compressor tool (1) from the
1871003100 tool kit and rotate the handwheel to
compress the clutch spring.
9. Install the bolts (2) hand tight.
10. Rotate the handwheel to unload the clutch
spring.
11. Remove the clutch compressor tool.
12. Install the three remaining clutch cover screws
hand tight.
13. Tighten the clutch cover screws in a crisscross
pattern to the proper (Torque Specifications).
14. Remove the 1860846000 flywheel holder tool
and 2000030800 clutch centering tool.
B.
ENGINE - POSITION ON STAND AND
REMOVE
REMOVAL
1. Install the 1860846000 flywheel holder tool (1).
2. Remove the bolts (2a) and the flywheel (2b).
3. Remove the 1860846000 flywheel holder tool.
4. With the aid of a hydraulic lift, install the engine
block to the 1871000000 maintenance stand (1).
FITMENT
1. With the aid of a hydraulic lift, remove the engine
from the 1871000000 maintenance stand.
2. Place the engine on a suitable platform.
